Model Name

408PEL+

408PE+

412PE+

Tốc độ in

101.6mm/sec

4"/sec

152.4mm/sec

6"/sec

101.6mm/sec

4"/sec

Độ phân giải

203dpi

203dpi

300dpi

Giao diện

Serial, Parallel, USB

Phương thức in

Thermal Transfer/Dirct Thermal

Độ rộng nhãn in

25mm to 108mm

Kiểu nhãn in

Roll Stock(Continuous or Die cut), Fan Fold, Tag Stock

Độ rộng nhãn

108mm

108mm

105.7mm

Độ dày của giấy in

0.06mm to 0.25mm

Các kiểu nhãn có thể in

Label gap, Black Mark and Punch hole sensing by auto sensing or program command setting

Mực

Industry standard : 25.4mm core diameter, 300m ribbon length-out side diameter of 68mm

Khoang chứa giấy

Durable plastic with Black transparent media window

Mã vạch 1D và 2D

Code 39, COde93, Code 128(Sub set A, B, C), UCC128, UCC/EAN-128, UPC A/E(add on 2&5), Interleaved 2 of 5, EAN128, EAN8/13(add on 2&5), Codabar, PostNET, DUN14, MaxiCOde, HIBC, Plessey, RPS128, PDF417, Datamatrix, QR code

Xử lý hình ảnh

PCX, BMP files

Ngôn ngữ máy in

ALL command, Firmware down loadable

Fotn Download

Windows Bitmap fonts and Asian fonts

Bộ nhớ

8MB SDRAM, 4MB Flash

Giao diện kết nối

Baud Rate 9600`115200, XON/XOFF, DSR/DTR

Phần mềm

Windows Label making software, Windows drivers

Màn hình LED

2 LED, 1 Function key

Nguồn cung cấp

External power supply 100/240VAC, 50/60Hz

Nhiệt độ hoạt động

5 to 40 centigrade

Độ ẩm

30 to 85% Non-condensing. Free Air

Approval

CE, FCC Class A, CCC, CB, CUL, BSIM

Kích thước

171mm H x 226mm W x 285mm D

Trọng lượng

2.7KG

Tùy chọn

Rotary cutter
Stripper Module
CF Card Adapter with RTC
Internal Ethernet Adapter Card

Material

Name

Features

Compatible paper

Usage

Wax type

ＡＮ

Low cost standard ink ribbon. High
transferability against pulp type label.
Low durability.

Pulp
type

Wood Free paper
/Coated paper

For Logistics
Management for entering and
dispatching/sorting

Low cost label for general logistics
Label for mass production
Refrigeration/Water resistance label

ＡＮＨ

High sensitivity ink ribbon. Suitable for
high density high speed printingon pulp
type label.
Low durability.

High transferability
coated paper

Semi resin type
(Wax + Resin)

ＡＴ

Semi resin ribbon with high transferability
against coat paper much like AN.
Obtains some endurance and water
resistance by combining with label.
This is the ribbon with some durability
against scratch.

Coated paper/
Mirror coated paper

Resin type

ＡＲ

High transferability against film type label.
Possesses heat resistant, water resistant,
durability against scratch, weather corrosion,
and solvent resistance.
Most affordable ribbon among resin type
ribbon that has good adoptability among
various ribbon types.

Film
type

Synthetic paper

Polyester Film label

Namer

For manufacturing
Product name plate/Management of
production assembling

High endurance label (Product name plate)

Heat resistant label
(For engine, printed board)

Chemical corrosion resistant
(For metal drum)

Weather corrosion resistant
(For out door use/PL labeling)

ＨＤ

High transferability against film type label.
Possesses heat resistant, water resistance,
durability against scratch, weather corrosion,
and solvent resistance. Most durable ribbon
against scratch among various types of ribbon.
Recommended for precise printing.

Synthetic paper

Polyester Film label

Namer

ＲＰ

High transferability against film type label.
Possesses heat resistant, water resistance,
durability against scratch, weather corrosion,
and solvent resistance.
Most solvent resistant among various ribbons.
(Against alcohol and chlorofluorocarbon)
The second most durable

Synthetic paper

Polyester Film label
